Shenzhen Lean Kiosk Systems CO., LTD
Product Details
| Place of Origin: | Kiosk manufacturer |
|---|---|
| Brand Name: | Lien |
| Certification: | FCC, CE, ROHS |
| Model Number: | LKS8318A |
Payment & Shipping Terms
| Min Order: | 1 unit |
|---|---|
| Price: | $ |
| Packaging: | Strong Case |
| Delivery Time: | 5-6 weeks |
| Payment Terms: | TT |
| Supply Ability: | 5000 units per month |
Detailed Product Description
The LKS8318A Weatherproof Half Outdoor Kiosk is designed for secure, reliable payment and ticketing in semi-outdoor environments. Built with anti-dust, anti-vandal steel construction and multiple screen sizes (17–19 inch), it supports bill, card, and coin payments, ideal for parking lots, subways, banks, and hospitals. With modular design, stable hardware, and full customization options, this kiosk delivers 24/7 self-service with durability and efficiency.
| Model | LKS8318A | OS Support | Windows 7, XP, Linux |
| Screen Size | 17" / 19" (Optional: 8” to 65”) | Touch Type | IR, SAW, or Capacitive |
| Material | 1.5–2.5mm Cold-rolled steel, Anti-dust, Anti-vandal | Brightness | 250cd/m²; Resolution: 1280×1024 |
| Main Components | PC, Card Reader, Bill Acceptor, Coin Acceptor, Receipt Printer, UPS | Peripheral Options | Cash dispenser, Barcode scanner, A4 printer, RFID reader |
Highlight: Weatherproof Outdoor Kiosk, Floor Standing Outdoor Kiosk, Outdoor Payment kiosk, outdoor Parking Kiosk | |||
Specifications of Weatherproof Outdoor Kiosk
|  |
All-Weather Protection: Engineered with weatherproof construction and IP65-rated sealing, ideal for semi-outdoor environments such as covered parking lots or metro stations.
High Durability: Built with 1.5mm–2.5mm cold-rolled steel cabinet, offering dustproof, rustproof, anti-corrosion, anti-static, and vandal-resistant protection.
System Compatibility: Supports Windows 7 / Linux, enabling flexible software customization to meet various application needs.
Easy Maintenance: Modular design allows fast replacement of components like card readers, bill acceptors, and printers, significantly reducing maintenance time and cost.
Multiple Payment Options: Compatible with card readers, encrypted PIN pads, QR/barcode scanners, coin/bill acceptors, and thermal printers for versatile self-service payments.
Wide Application Scenarios: Specifically designed for high-traffic and demanding environments such as parking lots, metro stations, banks, hospitals, theaters, highways, and airports.
 | Features of Weatherproof Outdoor Kiosk
|
Applications
| Customizations
|
The semi-outdoor payment kiosk price varies depending on configuration. The typical range is USD $1,500–$3,500 per unit. We support bulk orders (starting from 10 units) and offer full OEM customization including screen size, color, branding, and payment module options.
This outdoor kiosk terminal features industrial-grade components such as Seavo/Gigabyte motherboards, Intel i3/i5/i7 CPUs, 500GB HDD, and 8GB RAM. All parts undergo strict stress testing and environmental adaptation to ensure 24/7 operation in demanding conditions.
The self-service payment kiosk uses a modular structure, allowing easy swap-out of touch panels, printers, or bill acceptors. Remote diagnostics, real-time alerts, and guided replacement instructions ensure fast on-site troubleshooting with minimal downtime.
The kiosk’s touchscreen is built with reinforced tempered glass, rated for over 50 million touch cycles. All input modules (buttons, PIN pads) are tested for 2 million mechanical actuations, while the cabinet coating is UV-protected for fade resistance even in outdoor environments.
Yes, this semi-outdoor kiosk machine operates in temperatures ranging from -20°C to +50°C. It is IP65-rated for dust and water resistance and includes intelligent fan cooling systems to maintain performance in humid, hot, or dusty conditions.
Our semi-outdoor payment kiosk comes with a 1-year warranty and lifetime technical support, including remote software updates, troubleshooting assistance, and replacement guidance. For large orders, we also provide spare part kits and on-site engineer training if needed.
